The Odyssey (OS) series is the very first original FGN guitar. It was designed with precision & detail stemming from a long history of guitar manufacturing experience. These guitars are relatively simple with a traditional taste yet sport very useful modern & practical features for today's musicians.
Circle Fretting System (C.F.S.)
All FGN guitars and basses come with a unique Circle Fretting System (C.F.S.). It was created by FGN based on an idea to offer better pitch and articulation than conventional guitars and basses. All frets are installed on fingerboard in slightly curved shape, so that every string crosses all the frets in 90 degrees, i.e. to offer a minimum contact of string on a fret, and it makes the scale length of every string even while it actually varies on conventional fretting. The C.F.S. is a solution of fretting on a traditional guitar and bass and it offers clearer articulation and tones which give dimension when you play a cord and also cut through the mix when you play single notes.
Compound radius fingerboard
The compound radius fingerboard has smaller (rounder) radius towards nut while larger (flatter) radius towards neck end i.e. similar to a shape of a cone. This allows for much easier chord playing at lower frets while having less stress, especially when bending strings at higher registers.
Specification Sheet
Construction | Bolt-on Neck |
---|---|
Body | Flamed Maple Top / Ash Back |
Neck | Maple Quarter Sawn U-Shape |
Fingerboard | Rosewood |
Scale | 25.5" (648mm) |
Frets | 22F Narrow Tall C.F.S. / Xpert Fret Edge Treatment |
Tuners | GOTOH® SD91-05M MG |
Bridge | GOTOH® 510TS-FE1 |
Tailpiece | - |
Hardware Color | Gold |
Pickup (Neck) | FGN OS-2n |
Pickup (Middle) | FGN OS-2rw |
Pickup (Bridge) | FGN XPERT-Hf |
Controls | 1Volume, 1Tone, 5Way Lever SW, 2 Mini Tricky SW |
Body Finish | Gloss |
Strings | D'Addario EXL110 (.010-.046) |
Others | - |
Accessories | Original Hard Case, Fret Guard |
Color | RKG (Ripe Kaki Gradation) |
